Pneumatic PFA Lined Plug Valve
Pneumatic PFA Lined Plug Valve by YFL
Pneumatic PFA Lined Plug Valve
    The YFL Pneumatic PFA Lined Plug Valve has body and plug lined with PFA and seat in material of PTFE or PPL to be suitable for corrosive service in Chemical, Oil & Gas etc.
Inquiry Now
  • Features
  • Specification

Product range:

Size: 2"—26", DN50—DN650

Pressure rating: Class 150lbs—2500lbs, PN16—PN420

End connection: RF/RTJ/BW

Body materials: WCB/WC6/CF8/CF8M/CF3/CF3M+lined with FEP/PTFE/PFA

Plug materials: CA15/F6a/CF8/CF8M/CF3/CF3M+lined with FEP/PTFE/PFA

Sleeve: PTFE/PPL

Operation: Bare stem/Wrench/Gear/Electric/Pneumatic

Technical standards:

Design: API 599/API 6D

Face to Face: ASME B16.10/DIN3202 F1

BW ends: ASME B16.25/ASME B31.8

Flanged ends: ASME B16.5/DIN2543-2549

Test and inspection: API 598/DIN3230/Spark test

Pressure and temperature rating: ASME B16.34
